Choosing a fold is not a decorative decision. The fold you pick decides how many panels you get, how the reader discovers your content, what the piece costs to produce and whether it can be mailed without an envelope. This guide breaks down the 11 types of brochure folds you will actually be quoted on by a commercial printer, with panel counts, finished sizes, a concrete use case for each (menu, spec sheet, event program, price list) and the production constraints that come with it.
Quick reference: all 11 brochure folds at a glance
Flat sizes below use the two most common starting sheets: US Letter (8.5 x 11 in) and A4 (210 x 297 mm). “Panels” counts printable faces, front and back combined.
| Fold | Panels | Typical flat size | Finished size | Best for |
|---|---|---|---|---|
| Half fold (bi-fold) | 4 | 11 x 8.5 in / A4 | 5.5 x 8.5 in / A5 | Dine-in menus, short programs |
| Trifold (letter fold) | 6 | 11 x 8.5 in / A4 | 3.67 x 8.5 in / 99 x 210 mm | Takeout menus, service overviews |
| Z-fold | 6 | 11 x 8.5 in / A4 | 3.67 x 8.5 in / 99 x 210 mm | Step-by-step content, timelines |
| Accordion fold (4 or 5 panel) | 8 or 10 | 11 x 8.5 in / 14 x 8.5 in | 2.75 x 8.5 in | Product lines, comparison grids |
| Roll fold (4 panel) | 8 | 14 x 8.5 in / 297 x 210 mm+ | 3.5 x 8.5 in | Sequential storytelling, catalogs |
| Double parallel fold | 8 | 11 x 8.5 in / A4 | 2.75 x 8.5 in | Technical spec sheets, inserts |
| Gate fold | 6 | 11 x 8.5 in / A4 | 5.5 x 8.5 in closed | Reveal effect, wine lists |
| Double gate fold | 8 | 17 x 11 in / A3 | 4.25 x 11 in | Luxury launches, real estate |
| French fold (quarter fold) | 8 (often 4 printed) | 17 x 11 in / A3 | 8.5 x 5.5 in / A5 | Invitations, poster + booklet |
| Map fold (cross fold) | 12 to 16+ | 17 x 11 in and larger | Approx. 4 x 5.5 in | Festival maps, city guides |
| Stepped fold (tiered) | 6 to 10 | Custom, usually 11 x 8.5 in+ | Variable, staggered edges | Price tiers, packages, set menus |
How to choose a brochure fold in five questions
- How much content do you really have? Under 300 words plus one image fits a half fold. Between 300 and 800 words fits a trifold or Z-fold. Above that, move to 8 panels or a stitched booklet.
- Is the content sequential or modular? Sequential content (a process, a timeline, a tasting order) suits Z-fold, roll fold and accordion. Modular content (independent sections) suits trifold and double parallel.
- Does it need a reveal? Gate folds and double gate folds create a moment when the panels open. Use them when the image is the message.
- Will it be mailed, racked or handed out? Racks need a narrow finished width (around 3.67 in or 99 mm). Self-mailers need a closed edge and a mailing panel.
- What is the paper weight? Anything above roughly 100 lb text (150 gsm) needs scoring before folding, and tight folds like double parallel or double gate struggle on cover stock.
1. Half fold (bi-fold)
One fold down the middle of the sheet, giving four panels: front cover, two inside panels and a back cover. It is the simplest and cheapest fold to produce.
- Panels: 4
- Common sizes: 11 x 8.5 in folds to 5.5 x 8.5 in; A4 folds to A5; 11 x 17 in folds to 8.5 x 11 in
- Content it handles best: one big image plus a short block of copy, or a two-page spread that needs to be read at once
Use case: a dine-in restaurant menu
The half fold gives you a full spread when opened, which is exactly how guests read a menu: starters on the left, mains on the right, drinks on the back. It also survives handling better than folds with multiple creases. Print it on a 12 pt to 14 pt coated cover stock or laminate it if the menu stays on the table.
Printing constraints
- Score first on any stock over 150 gsm to prevent cracking along the spine.
- Run the fold parallel to the paper grain for a clean crease.
- Watch the gutter: do not place small text within 0.25 in (6 mm) of the centre fold.
2. Trifold (letter fold)
The default brochure. Two parallel folds divide the sheet into three sections, one panel wraps inside the other, producing six panels. This is what most people mean by a “3 fold brochure”.
- Panels: 6 (3 front, 3 back)
- Common sizes: 11 x 8.5 in folds to about 3.67 x 8.5 in; A4 folds to about 99 x 210 mm
- Content it handles best: three to six independent sections such as services, pricing, testimonials, contact
Use case: a takeout menu or a service overview
A trifold takeout menu fits a standard envelope and a counter rack, and the back panel doubles as an address panel for direct mail. Keep one panel for ordering information and a QR code that links to your digital menu so prices stay current between reprints.
Printing constraints
- The tucked-in panel must be shorter by 1/16 to 1/8 in (2 to 3 mm) or the brochure will bulge and refuse to lie flat.
- Set up the artwork so the short panel is panel 1 on the inside, not the cover.
- Heavy coverage over the creases on digitally printed stock will crack without scoring.
3. Z-fold
Same sheet, same two folds, same six panels, but the folds alternate directions so the piece opens like a concertina. Nothing is tucked inside, so every panel is the same width.
- Panels: 6
- Common sizes: identical to the trifold
- Content it handles best: a linear sequence, a timeline, a three-step process, or one large panoramic image spread across three panels
Use case: an event program or a tasting menu
Guests can fan out all three panels in one movement and see the full running order without flipping anything. For a wine tasting or a chef’s set menu, each panel becomes one course or one flight.
Printing constraints
- Panels are equal width, so no panel shortening is needed. That makes layout simpler than a trifold.
- Because no panel is captured, the piece springs open. For direct mail you will need a wafer seal or tab on the open edge.
4. Accordion fold (4 panel and 5 panel)
The Z-fold principle extended: three or more parallel folds, all alternating, giving 8, 10 or 12 panels. A 4-panel accordion on an 11 x 8.5 in sheet gives eight narrow panels.
- Panels: 8 (4-panel) or 10 (5-panel)
- Common sizes: 11 x 8.5 in folds to 2.75 x 8.5 in; 14 x 8.5 in folds to 3.5 x 8.5 in
- Content it handles best: a product range where each item gets its own narrow column, or a side-by-side comparison read across the open sheet
Use case: a product line sheet
Fully opened, an accordion becomes a single wide canvas for a comparison table. Closed, each panel is a self-contained product card. That dual reading is something a trifold cannot do.
Printing constraints
- Narrow panels mean tight margins. Keep at least 0.2 in (5 mm) of clear space on each side of every panel.
- On stock above 130 gsm the accordion becomes bulky and may need hand finishing, which raises cost.
- Cross-panel images need accurate folding registration, so ask for a folded proof.
5. Roll fold (4 panel)
Each panel folds inward over the previous one, rolling toward the centre like a scroll. Standard version uses four sections and eight panels, but six and eight section roll folds exist.
- Panels: 8
- Common sizes: 14 x 8.5 in folds to about 3.5 x 8.5 in; 17 x 11 in folds to about 4.25 x 11 in
- Content it handles best: a controlled narrative where panels are revealed one at a time
Use case: a guided sales story or a mini catalog
The roll fold is the strongest fold for a build-up: problem, solution, proof, offer. The reader cannot skip ahead easily, which is why it performs well in direct mail campaigns.
Printing constraints
- Every inner panel must be progressively shorter, usually by 1/16 in (1.5 to 2 mm) per panel. Your printer will supply a dieline. Do not guess.
- Not suited to thick cover stock. Above roughly 200 gsm the innermost panel will buckle.
- Ask for the template before you design, because the panel widths are not equal.
6. Double parallel fold
The sheet is folded in half, then folded in half again in the same direction. Result: eight panels in a compact, sturdy format that opens in two clean movements.
- Panels: 8
- Common sizes: 11 x 8.5 in folds to 2.75 x 8.5 in; 17 x 11 in folds to 4.25 x 11 in
- Content it handles best: dense, structured information such as specifications, dosage tables or technical data
Use case: a product spec sheet
Eight panels give you room for an overview, a full specification table, dimensions, compliance notes and contact details, in a piece that still slips into a jacket pocket or a shipping box.
Printing constraints
- The two inner panels need to be shortened slightly, similar to a trifold.
- Four thicknesses of paper stack at the spine, so stay at or below 150 gsm for a flat finish.
- Very narrow closed width limits headline sizes. Test your typography at actual size before approving.
7. Gate fold
Two outer panels fold inward to meet at the centre, like a pair of doors. The centre panel is double width. Total: six panels, one of which is the wide interior reveal. picklewix.com has covered this at length.
- Panels: 6 (two half-width flaps, one full-width interior)
- Common sizes: 11 x 8.5 in closes to 5.5 x 8.5 in; A4 closes to A5
- Content it handles best: one hero image or one hero offer that deserves a dramatic opening
Use case: a wine list or a signature dish presentation
Opening the two flaps to reveal a full-width photograph or the reserve wine selection creates a sense of occasion. It is also used for property listings and event invitations.
Printing constraints
- The two flaps must each be slightly narrower than half the sheet, typically by 1/16 in (1.5 mm), so they do not overlap at the centre.
- Gate folds often need a second pass on the folding machine, which adds cost on short runs.
- Consider a light coating so the flaps do not curl apart in humid conditions.
8. Double gate fold
A gate fold that is then folded in half again down the middle, so the piece opens twice: first like a book, then like doors. Gives eight panels and a premium feel. companyfolders.com walks through the specifics.
- Panels: 8
- Common sizes: 17 x 11 in closes to about 4.25 x 11 in; A3 closes to about 105 x 297 mm
- Content it handles best: a staged reveal with a wide final spread, ideal for imagery-led campaigns
Use case: a hotel, resort or property launch piece
The double gate gives you three distinct reveal moments, so you can move from teaser to detail to full panorama. Expect it to be the most expensive fold on this list per unit.
Printing constraints
- Requires precise panel step-downs on both flaps plus the outer fold. Always work from the printer’s dieline.
- Large flat sheet size pushes you onto larger presses, which changes pricing tiers.
- Often hand finished on runs under 1,000 copies.
9. French fold (quarter fold or right angle fold)
The sheet is folded in half, then folded in half again at a right angle to the first fold. You get eight panels, though the piece is frequently printed on one side only, giving four finished pages plus a hidden poster on the reverse.
- Panels: 8 (commonly 4 used)
- Common sizes: 17 x 11 in folds to 8.5 x 5.5 in; A3 folds to A5
- Content it handles best: short, elegant messaging on the outside with a large-format image inside
Use case: an event invitation or an opening announcement
French folds feel like a card but unfold into a poster. They are also used for instruction inserts where the inside becomes a single large diagram.
Printing constraints
- Only one fold can follow the grain, so the second fold may show slight roughness on uncoated stock.
- Cheap to produce because one-sided printing halves ink and plate work.
- Alignment at the corner where the two folds meet must be tight. Request a folded sample.
10. Map fold (cross fold)
An accordion fold in one direction followed by one or more folds at a right angle. Panel counts commonly reach 12, 16 or more, and the finished piece is small enough for a pocket.
- Panels: 12 to 16 and above
- Common sizes: 17 x 11 in and larger, closing to roughly 4 x 5.5 in
- Content it handles best: a single large-format graphic that must collapse to pocket size
Use case: a festival map or a city walking guide
When the whole point is one continuous illustration, this is the only fold that works. Listings, sponsor logos and a schedule go on the reverse in accordion panels. This is treated carefully on isfuckingbrilliant.com.
Printing constraints
- Use lightweight stock, typically 70 to 100 gsm, or the folded bulk becomes unusable.
- Multiple cross folds accumulate registration tolerance. Avoid critical detail at fold intersections.
- Folding is machine intensive and often priced separately from printing.
11. Stepped fold (tiered or staggered fold)
Panels of deliberately different depths, so when the brochure is closed you see a staircase of edges, each one showing a heading or a tab. Panel counts vary with the design, commonly six to ten.
- Panels: 6 to 10
- Common sizes: custom, usually built from an 11 x 8.5 in or larger sheet
- Content it handles best: comparable items that need instant navigation, such as tiers, packages or categories
Use case: a price list, a package comparison or a set menu
Each visible step carries a tier name (Essential, Plus, Premium) or a menu category. The reader scans the steps and opens directly at the one that matters. It is the best fold for decision-making content. Complete List of Brochure Folds and Options is a useful companion to this.
Printing constraints
- Requires trimming to uneven panel depths, so budget for die cutting or extra trimming.
- The stepped edges are visible, which means colour on those strips must be consistent across the run.
- Minimum step depth of about 0.4 in (10 mm) keeps the tab legible.
Match the content type to the fold
| You are producing | First choice | Alternative |
|---|---|---|
| Dine-in menu | Half fold | Gate fold |
| Takeout or delivery menu | Trifold | Z-fold |
| Wine or cocktail list | Gate fold | Double parallel |
| Product spec sheet | Double parallel | Accordion 4 panel |
| Event program | Z-fold | Half fold |
| Direct mail sales piece | Roll fold | Trifold |
| Invitation | French fold | Half fold |
| Pricing or package comparison | Stepped fold | Accordion |
| Venue or city map | Map fold | Accordion 5 panel |
| Premium property or hospitality launch | Double gate | Gate fold |
Printing rules that apply to every fold
- Panel shortening: any fold where a panel tucks inside another (trifold, roll fold, double parallel, gate) needs the inner panels trimmed by 1/16 to 1/8 in. Always request the dieline first.
- Grain direction: fold with the grain whenever possible. Folding against the grain causes cracking and a fibrous edge.
- Scoring: mandatory above roughly 150 gsm, and strongly recommended on any digitally printed piece with heavy toner coverage across the crease.
- Bleed and safety: 0.125 in (3 mm) bleed on all outer edges, and keep text 0.125 to 0.25 in away from every fold line.
- Self-mailers: postal services require a closed folded edge on the leading side plus sealing tabs on many folds. Check requirements before you commit to a Z-fold or accordion.
- Proofing: ask for a folded blank dummy on the actual stock. It costs almost nothing and catches thickness problems that a flat PDF will never show.
Common mistakes to avoid
- Designing a trifold on three equal columns in a page layout file, then discovering the folded piece will not close flat.
- Choosing an 8-panel fold on 300 gsm cover stock because it looked good on screen.
- Putting the call to action on the panel that ends up hidden inside the fold.
- Printing 5,000 menus with fixed prices that change within a month. Pair the print piece with a QR code that leads to a digital version you can update yourself.
- Ignoring the reading order. Number your panels 1 to 6 or 1 to 8 in the physical order the reader will meet them, not in the order they sit on the flat sheet.
Where digital menus fit alongside printed folds
Printed brochures and menus are still the strongest tool for atmosphere, hand-off moments and mailboxes. Their weakness is fixed content: one price change, one seasonal dish, one sold-out item and the whole run is out of date. The practical setup used by most venues today is a well-chosen fold for the physical piece plus a QR code linking to a live digital menu that handles daily specials, allergen details, translations and stock updates. The fold carries the brand, the digital layer carries the changes.
FAQ
What are the different types of folded brochures?
The most common are the half fold, trifold, Z-fold, accordion fold, roll fold, double parallel fold, gate fold, double gate fold, French fold, map fold and stepped fold. They differ in panel count (from 4 up to 16 or more), in whether panels tuck inside each other and in how the piece is revealed to the reader.
What are the different types of paper folds?
Paper folds fall into three families. Parallel folds have creases running in the same direction (half, trifold, roll, double parallel, accordion). Right angle folds cross each other at 90 degrees (French fold, map fold). Specialty folds combine techniques or use uneven panels (gate, double gate, stepped, pocket folds).
What are the 5 parts of a brochure?
Whatever the fold, a functional brochure has five parts: the front cover (hook and brand), the inside panels (main content), the call to action panel, the back cover (contact details, address or mailing panel) and the fold structure itself, which controls the order in which those parts are read.
What do you call a 3 fold brochure?
A brochure with three sections is called a trifold or letter fold brochure. It technically has two folds and three sections per side, for a total of six panels. If the two creases alternate direction instead of tucking one panel inside, the same sheet becomes a Z-fold.
Which brochure fold is cheapest to print?
The half fold, because it needs a single pass on the folding machine and no panel shortening. The trifold and Z-fold follow closely. Double gate folds, stepped folds and map folds cost the most because of extra folding passes, dies or hand finishing.
What is the standard trifold brochure size?
In the United States, 8.5 x 11 in flat, folding to roughly 3.67 x 8.5 in. In Europe, A4 (210 x 297 mm) flat, folding to roughly 99 x 210 mm. Both fit a standard brochure rack and a DL envelope.
How many panels does a roll fold brochure have?
A standard 4-section roll fold has eight panels, four on each side. Six and eight section versions exist, giving 12 or 16 panels, but they require progressively shorter inner panels and lighter paper stock.
